What's included

• 1 scoreboard
• 1 control console (Android compatible)
• 1 carrying case for control consoles
• 1 mains cable
• Junction box and transmission cables (for cable controlled version)
• Operating and installation instructions
• (Smartphone not included)

Description

Use : Indoor
Transmission : Radio (868 MHz) or cable
Readability : 60m, angle >160°
Dimensions : 1200 x 650 x 90mm
Weight : 16 kg
Power supply : 230V / 50-60Hz Power consumed: 72 VA
Protection : Unbreakable mat polycarbonate front face (DIN 18032-3)
Integrated Horn : 116dB at 1m
Mains cable (supplied) : 5 m – Type: 230V, 3G, 0.75 mm²
Cable controlled: For cable controlled models or radio controlled models with cable set:
Junction Box 50 m transmission cable (scoreboard/junction box) –
Type : phone cable 2 pairs 6/10th 10 m transmission cable DIN/DIN (junction
box/console)

Display functions

Score : 2 x 3 red LED digits (15 cm)
Period : 1 red LED digit (12 cm)
Timer/Rest period : 4 red LED digits (15 cm) blinking points
Team fouls (BB)/ Exclusion timer : 2 x 1 red LED digits (12 cm)
Time out (BB, HB, VB)/
Number of exclusions (HB) : 2 x 3 red points
Day Time : When the scoreboard is not in use

Control consoles

1 console : (340 x 175 x 60 mm) with LCD screen with 2 lanes of 20 characters (9mm high) - Main console : management of the main functions
1 charger : Hold the consoles in charge when there are not in use. (Autonomy max 16 h)
Connexion plugs : DIN between the consoles
USB Port : For program update or connect PC keyboard
Programme : 14 sport disciplines « Free mode » to create your own sport discipline or for additional sports (wrestling, Pelota…)
Multilingual Programme

Options

TV Interface (RS 485) : Data transmission for TV broadcasting
Sound Interface : Connection with sport hall sound system - Horn sound amplifier
DCF or GPS Antenna : For accurate time synchronisation
Cable set : Cable mode for radio controlled scoreboard
24 sec shot clock : Attack timer with or without main time repeater
Led Strip : Electric light to be installed behind the backboard, connected with the 24 second shot clocks, synchronised with the main timer to light up at the end of each period.
MPA : Ball possession indicator (FIBA Level 1)
Wheel Stand
