GENERAL SPECIFICATIONS
-
- Cooling Capacity: 2,7 kW, 9,212 BTU/h
- Heating Capacity: 2,93 kW, 9,997 BTU/h
-
- Compressor Type: Twin Rotary
- Refrigerant R410A
-
- EER: 3,70 W/W, 12,64 (BTU/h)/W
- COP: 3,80 W/W, 12,97 (BTU/h)/W
-
- Type: Wall-mounted
- Colour: White
INDOOR
-
- Fan Type: Cross Flow Fan
- Motor Output: 30 W
-
- Sound Pressure Level
- Cooling, Max: H: 42/M: 36/L: 28/SL: 21 dB(A)
Heating, Max: H: 42/M: 36/L: 28 dB(A)
- Air Flow Rate
- Cooling, Max: 12.5/H: 9.3/M: 7.2/L: 2.7 m³/min
Heating, Max: 13/H: 10/M: 7/L: 5.5 m³/min
OUTDOOR
-
- Fan Type: Propeller Fan
- Motor Type: AC
-
- Sound Pressure Level
- Cooling, Rated 51 dB(A)
Heating, Rated 53 dB(A)
- Air Flow Rate: Max 27,0 m³/min
-
- Piping: Ø 6.35, Ø 9.52
- Drain Hose Size: O.D 21.5 mm, I.D 16.0 mm
POWER
-
- Cooling: 729 W
- Heating: 771 W
-
- Cooling Running Current: 3,50 A
- Heating Running Current: 3,60 A
-
- Power Supply: 1Ø, 220 ~ 240V, 50 Hz
- Available Voltage Range: 187 ~ 276 V
-
- Power Factor: 94%
- Circuit Breaker: 15 A
DIMENSIONS
-
- Indoor Dimensions: 837 × 308 × 189 mm
- Indoor Weight: 8,4 kg
-
- Outdoor Dimensions: 717 × 483 × 230 mm
- Outdoor Weight: 26,4 kg
BETWEEN INDOOR & OUTDOOR
-
- Piping length: Min: 3.6 m; Standard: 7.5 m; Max: 15 m
- Max Elevation Difference: 7 m
-
- Piping Connection Heat Insulation: Both liquid and gas pipes
